Radar level measurement

Eenvoudige producten
Gemakkelijk te selecteren, installeren en gebruiken

Technische topkwaliteit

Eenvoud

Wat is FLEX?

Standaardproducten
Betrouwbaar, robuust en onderhoudsarm

Technische topkwaliteit

Eenvoud

Wat is FLEX?

High-end producten
Functioneel en uiterst doelmatig

Technische topkwaliteit

Eenvoud

Wat is FLEX?

Gespecialiseerde producten
Ontworpen voor veeleisende applicaties

Technische topkwaliteit

Eenvoud

Variabel

Wat is FLEX?

FLEX selectie	Technische topkwaliteit	Eenvoud
F L E X Fundamental selectie Voldoe aan uw basismeetvoorwaarden	Technische topkwaliteit	Eenvoud
F L E X Lean selectie Beheers eenvoudig uw belangrijkste processen	Technische topkwaliteit	Eenvoud
F L E X Extended selectie Optimaliseer uw processen met innovatieve technologieën	Technische topkwaliteit	Eenvoud
F L E X Xpert selectie Beheers uw meest uitdagende applicaties	Technische topkwaliteit	Eenvoud Variabel

Meer informatie over de FLEX selecties

New

Vergelijken

Micropilot FMR43 – radarsensor voor hygiënische processen

Hoogwaardige sensor, bijzonder compact en perfect geschikt voor snel veranderende niveautoepassingen

Accuracy +/-1 mm (0.04 in)

Process temperature -40 to +150 °C
(-40 to +302 °F)

Process pressure / max. overpressure limit -1 to +20 bar
(-14.5 to +290 psi)

Max. meetafstand 15 m (49 ft)

Main wetted parts PEEK
PTFE
316L (for threaded connections)

New

Vergelijken

Micropilot FMR10B – radar sensor for basic applications

Simple operation of level measurement in liquids and solids

Accuracy +/- 5mm (0.2")

Process temperature -40…+60°C
(-40…+140°F)

Process pressure / max. overpressure limit -1…3 bar
(-14,5…43 psi)

Max. meetafstand 10m (32.8 ft)

Main wetted parts PVDF, PBT/PC

New

Vergelijken

Micropilot FMR20B - radar sensor for basic applications

Simple and efficient level measurement in liquids and solids

Accuracy +/- 2mm (0.08")

Process temperature -40…+80°C
(-40…+176°F)

Process pressure / max. overpressure limit -1…3 bar
(-14,5…43 psi)

Max. meetafstand 40 mm/ 1-1/2": 20m (65.6 ft)
80 mm/ 3": 30m (98.4 ft)

Main wetted parts PVDF, PBT/PC

New

Vergelijken

Micropilot FMR30B - radar sensor for basic applications

Simple and efficient level measurement in liquids and solids

Accuracy +/- 2mm (0.08")

Process temperature -40…+80°C
(-40…+176°F)

Process pressure / max. overpressure limit -1…3 bar
(-14,5…43 psi)

Max. meetafstand 30m (98.4 ft)

Main wetted parts PVDF, PBT/PC

Vergelijken

Radarmeting Time of Flight Micropilot FMR52

Voor niveaumetingen in agressieve vloeistoffen of toepassingen waarbij hoge eisen worden gesteld aan hygiëne

Accuracy +/- 2 mm (0.08 in)

Process temperature -196...+200 °C
(-321...+392 °F)

Process pressure / max. overpressure limit Vacuum...25 bar
(Vacuum...363 psi)

Max. meetafstand Standard: 40 m (131 ft)
With advanced dynamics: 60 m (197 ft)

Main wetted parts PTFE

Vergelijken

Radarmeting Time of Flight Micropilot FMR57

De standaardsensor voor niveaumetingen in stortgoederen

Accuracy +/- 3 mm (0.12 in)

Process temperature -40...+400 °C
(-40...+752 °F)

Process pressure / max. overpressure limit Vacuum...16 bar
(Vacuum...232 psi)

Max. meetafstand 70 m (230 ft)

Main wetted parts 316L, PEEK, PTFE, Polyamid

Vergelijken

Micropilot FMR60B – 80GHz-radarsensor

Meer eenvoud in uw toepassing

Accuracy +/-1 mm (0.04 in)

Process temperature -40 … +200 °C (-40 … +392 °F)

Process pressure / max. overpressure limit Vacuum...20 bar (290 psi)

Max. meetafstand 50 m (164 ft)

Main wetted parts PVDF, PTFE or PEEK

Vergelijken

Micropilot FMR62B – 80GHz-radarsensor

Slimme veiligheid voor uw proces

Accuracy +/-1 mm (0.04 in)

Process temperature -196 … +450 °C (-321 … +842 °F)

Process pressure / max. overpressure limit Vacuum...160 bar (2320 psi)

Max. meetafstand 80 m (262 ft)

Main wetted parts 316L or PTFE (clad 316L flanges)

Vergelijken

Micropilot FMR63B – 80GHz-radarsensor

Meer eenvoud met de specialist voor hygiënische toepassingen

Accuracy +/-1 mm (0.04 in)

Process temperature -40 °C … +200 °C (-40 °F … +392 °F)

Process pressure / max. overpressure limit Vacuum...25 bar (363 psi)

Max. meetafstand 80 m (262 ft)

Main wetted parts PEEK or PTFE

Vergelijken

Micropilot FMR66B – 80GHz-radarsensor

De beste prestaties in elke toepassing

Accuracy +/- 3 mm (0.12 in)

Process temperature -40 … +130 °C (-40 … +266 °F)

Process pressure / max. overpressure limit Vacuum...16 bar (232 psi)

Max. meetafstand 50 m (164 ft)

Main wetted parts PVDF or PTFE

Our product finder helps you to search for suitable measuring devices, software or system components via product characteristics. Applicator leads you through an individual product selection via application parameters.

Go to product finder Go to Applicator

About radar level measurement

Radar level measurement with top-down installation of a Micropilot sensor offers perfect application fit in all industries. Non-contact radar with simple commissioning, trouble-free operation saves time and money. For usage in a wide range of applications - be it in simple storage tanks, in corrosive or aggressive media or high accuracy tank gauging applications. Check out the broad range of Micropilot devices for radar applications and click on the button below.

Radar level measurement is a safe solution even under extreme process conditions (pressure, temperature) and vapors. Micropilot can also be used in hygienic applications for non-contact level measurement. Micropilot versions are available for different industries like for water/wastewater, the food industry, life sciences or the process industry. Various antenna versions for every kind of radar applications are available.

Radar measurement: Measuring Principle

Micropilot works with high-frequency radar pulses which are emitted by an antenna and reflected from the medium surface due to a change of the dc value (relative dielectric constant). The Time-of-Flight of the reflected radar pulse is directly proportional to the distance traveled. If the tank geometry is known, the level can be calculated from this variable.

Benefits

Non-contact, maintenance-free measurement
Unaffected by medium properties like density and conductivity, in bulk solids also unaffected by filling noise and dust
Freely adjustable measuring range
For high temperatures up to +450°C/+842°F
